YH16003 Pro RTR 1/16 2.4G 4WD RC Car Off-Road High Speed 70km/h Full Proportional Control Brushless Vehicles Models - Red
Description
Specification:
|
Basic information |
Models:YH-16003 Pro Model:1/16 Speed:About 70km/h |
Power system |
ESC and receiver are 2 in 1,35A 2S Motor:Brushless 2847 3200kv Servo:3 line 17g |
Transmitter |
Frequency:2.4 GHZ Battery: 3XAA battery(not included) |
Battery: |
7.4V 1600mAH 20C T plug |
others |
Charge time:3-3.5h Using time:18min Control distance:80m Function:acceleration, deceleration, left turn, right turn Proportional control:Fully proportional Differential:Metal differential Car light configuration:LED headlights |
Dimension |
Size:29.1*23.6*12.6 CM Wheelbase:185mm Track width:188mm Wheel diameter:85mm Package size:30.6*16*25.6 CM Car weight:953.6g |
Features:
1. Realistic car handling feel, achieving fully proportional continuously variable transmission (CVT), high-speed driving, rapid acceleration, deceleration, braking, reversing, left turns, and right turns;
2. Applicable terrains: flat ground, sand, mud, and grass.
3. Four-wheel drive: Front and rear vertical spring shock absorbers, double wishbone independent suspension system;
4. 2.4G full-proportion synchronous remote control system. Full-proportion throttle/steering;
5. Metal differential, metal differential cup, powder planetary gear, powder drive gear, powder main gear;
6. Metal CVD front drive shaft, metal rear dogbone, metal wheel cups;
7. Three-wire 17G metal servo motor;
8. 7.4V, 18650-1600mAh Li-ion battery (T plug), discharge rate 20C;
9. Added remote control panel function: servo adjustment;
10. 16 ball bearings throughout the vehicle;
11. Metal second floor plate, metal front and rear arm brackets, metal center drive shaft;
12. High-toughness explosion-proof PVC body shell;
13. Equipped with LED headlights; with on/off function;
14. Equipped with wheel lifters;
15. Simulated large-foot tires, strong grip;
Note:
1. Charging protection: Constant-current, constant-voltage balanced charging; includes protection against battery overcharge and overcurrent.
2. Motor stall protection: The motor stops operating under overload conditions.
3. High-temperature protection: The drive control circuit stops operating when the working temperature exceeds the set limit and resumes once the temperature drops to a safe level.
4. ESC low-voltage cutoff: Automatically cuts power when the battery voltage drops below approximately 6.3–6.4V to prevent damage from over-discharge.
Package Included:
1 x RC car
1 x Remote control
1 x Lithium battery
1 x USB charger
1 x Rear wing
1 x Wheelie bar
1 x pins
1 x Phillips screwdriver
1 x English product manual
