Micsig ATO2004 Digital Oscilloscope Automotive 200MHz 220Mpts Portable oscilloscopes touchscreen Table diagnostic oscilloscope

Micsig ATO2004 Digital Oscilloscope Automotive 200MHz 220Mpts Portable oscilloscopes touchscreen Table diagnostic oscilloscope

Features:

With the HTI HT-18+, never miss a detail with its impressive 256x192 infrared resolution, ensuring sharp thermal images at all times. Capture every minute detail to accurately diagnose and address any thermal anomalies you come across.

Opt for versatility and clarity as this device operates in a broad wavelength range of 8-14μm. Whether it's for construction, PCB detection, or temperature measurement, the HT-18+ has got you covered.

Revel in the comfort of personalizing your thermal readings with adjustable emissivity settings, ranging from 0.01 to 1, ensuring accurate temperature measurements irrespective of the material you're inspecting.

Dive into the user-friendly 3.2" full angle TFT screen, presenting a suite of color palettes like rainbow, iron red, cold color, white hot, and black hot. Choose the palette that resonates best with your inspection needs.

Enhance your analysis with the in-built feature of software analysis. Couple this with the capability to record videos, and you're all set to document, analyze, and archive your findings efficiently.

Specifications:

Model ATO2004

Bandwidth 200MHz

Analog Channels 4

Sampling Rate (Max.)  2GSa/s

Memory Depth 220Mpts

Waveform Capture Rate (Max.) 300,000 wfms/s

Support Tests High Pass / Low Pass (to 30Hz)

Segmented storage Support to capture max 10,000 events

Support Tests Charging/Start Circuits, Sensors, Actuators,

Ignition, Networks (CAN L/H, CAN FD, LIN, Flexray, K line),

Combination Tests

Interfaces Wi-Fi, USB 3.0/2.0 Host, USB Type-C, Grounding,

HDMI, Trigger out

Display Industrial 10.1" TFT-LCD (1280*800), 11*10 divisions

Dimension / Net Weight 265*192*50mm / 1.9kg (with battery)

Battery / Duration 7.4V, 7500mAh / 5H 7.4V, 7500mAh / 2H

Package included:

1 x Digital Oscilloscope

1 x Battery (build in)

1 X Power Cord

1 x Adapter

4 x Aligator Clips

2 pair x Soft Pin Probes

4 x BNC to Banana Leads

2 x Passive Probes

1 x Protective film
